LD CQAR-APAR-24-1-700-R18
LED OSLON SIGNAL BLUE 451NM SMDManufacturer: ams-OSRAM USA INC.
Categories: LED Color Lighting
Quality Control: Learn More
ams-OSRAM USA INC. OSLON® Signal series blue LED, part number LD-CQAR-APAR-24-1-700-R18. This surface mount device features a 451nm peak wavelength (444nm to 457nm range) with a typical forward voltage of 3.05V at 700mA test current. The LED delivers a luminous flux of 1260mW (1120mW to 1400mW) under test conditions. With a maximum forward current of 2A, it is housed in a 1212 (3030 Metric) SMD package measuring 3.00mm x 3.00mm. The seated height is a maximum of 1.95mm, and it offers a wide 120° viewing angle. Supplied on tape and reel, this component is suitable for applications in automotive lighting, industrial signaling, and general illumination where precise blue light output is required.
Additional Information
Series: OSLON® SignalRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 1212 (3030 Metric) |
| Color | Blue |
| Wavelength | 451nm (444nm ~ 457nm) |
| Size / Dimension | 0.118"" L x 0.118"" W (3.00mm x 3.00mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 3.05V |
| Current - Test | 700mA |
| Viewing Angle | 120° |
| Current - Max | 2A |
| Supplier Device Package | SMD |
| Lumens/Watt @ Current - Test | - |
| Height - Seated (Max) | 0.077"" (1.95mm) |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 1260mW (1120mW ~ 1400mW) |
