LCG H9RM-LXMX-2-0-350-R18-Z
LED COB OSTAR GREENManufacturer: ams-OSRAM USA INC.
Categories: LED Color Lighting
Quality Control: Learn More
The ams-OSRAM USA INC. OSRAM OSTAR® Projection Cube LCG-H9RM-LXMX-2-0-350-R18-Z is a high-performance green LED COB designed for demanding illumination applications. This component delivers a luminous flux of 161 lumens at a typical forward voltage of 2.97V and a test current of 350mA, achieving an efficacy of 160 lm/W at 25°C. With a maximum forward current of 500mA, it offers substantial light output within its compact 3.75mm x 3.75mm footprint. The LED features a wide 120° viewing angle and a low seated height of 0.60mm, making it suitable for surface-mount integration into various optical systems. This device is supplied in Tape & Reel packaging and finds utility in projection systems, automotive lighting, and architectural illumination.
Additional Information
Series: OSRAM OSTAR® Projection CubeRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Color | Green |
| Wavelength | - |
| Size / Dimension | 0.148"" L x 0.148"" W (3.75mm x 3.75mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 2.97V |
| Current - Test | 350mA |
| Viewing Angle | 120° |
| Current - Max | 500mA |
| Supplier Device Package | SMD |
| Lumens/Watt @ Current - Test | 160 lm/W |
| Height - Seated (Max) | 0.024"" (0.60mm) |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 161lm (112lm ~ 210lm) |
Request a Quote
