LA C9SM-CADB-24-1-Z
LED CERAMOS AMBER 618NM SMDManufacturer: ams-OSRAM USA INC.
Categories: LED Color Lighting
Quality Control: Learn More
ams-OSRAM USA INC. CERAMOS Series LED, part number LA-C9SM-CADB-24-1-Z, is a surface-mount amber illumination component with a peak wavelength of 618nm (612nm to 624nm). This 0806 (2016 Metric) package measures 2.10mm x 1.65mm and has a maximum seated height of 0.85mm. It is supplied in Tape & Reel packaging. The device exhibits a typical forward voltage of 2.1V and a maximum forward current of 200mA, with a test current of 140mA. At 140mA test current and 25°C, it provides a luminous flux of 14lm (10lm to 19lm) and an efficacy of 48 lm/W. The viewing angle is 120°. This component is suitable for automotive lighting, industrial indicators, and general signage applications.
Additional Information
Series: CERAMOSRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 0806 (2016 Metric) |
| Color | Amber |
| Wavelength | 618nm (612nm ~ 624nm) |
| Size / Dimension | 0.083"" L x 0.065"" W (2.10mm x 1.65mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 2.1V |
| Current - Test | 140mA |
| Viewing Angle | 120° |
| Current - Max | 200mA |
| Supplier Device Package | SMD |
| Lumens/Watt @ Current - Test | 48 lm/W |
| Height - Seated (Max) | 0.033"" (0.85mm) |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 14lm (10lm ~ 19lm) |
