LZ1-10R100-0000
LED MOD LZ1 RED STARBOARDManufacturer: ams-OSRAM USA INC.
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
The ams-OSRAM USA INC. LZ1 Series LED Module, part number LZ1-10R100-0000, is a red LED module designed for high-performance lighting applications. This component features a 3.20mm diameter Light Emitting Surface (LES) and a domed lens, providing efficient light distribution with a typical viewing angle of 76°. Operating at a forward voltage of 2.6V, it can handle a maximum current of 1.2A, with a test current of 1A yielding 62 lm/W. At the test current and temperature, it produces 160 lumens. The module has a diameter of 19.90mm and a height of 4.50mm. This red LED module is commonly utilized in automotive lighting, architectural lighting, and general illumination systems where precise color and brightness are critical. It is supplied in tray packaging.
Additional Information
Series: LZ1RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tray |
| Color | Red |
| Wavelength | 623nm |
| Size / Dimension | 19.90mm Dia |
| Type | LED Module |
| Configuration | Starboard |
| Voltage - Forward (Vf) (Typ) | 2.6V |
| Height | 4.50mm |
| Current - Test | 1A |
| Viewing Angle | 76° |
| Lens Type | Domed |
| Current - Max | 1.2A |
| Lumens/Watt @ Current - Test | 62 lm/W |
| CCT (K) | - |
| CRI (Color Rendering Index) | - |
| Light Emitting Surface (LES) | 3.20mm Dia |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 160lm (117lm ~ 228lm) |
