LZ1-10A102-0000
LED MOD LZ1 AMBER STARBOARDManufacturer: ams-OSRAM USA INC.
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
ams-OSRAM USA INC. LZ1 Series LED Module, part number LZ1-10A102-0000. This amber LED module features a 3.20mm diameter Light Emitting Surface (LES) and a domed lens. It operates with a typical forward voltage of 2.6V and a maximum current of 1.2A, delivering 84 lumens at a test current of 1A. The module exhibits a luminous efficacy of 32 lm/W at 25°C. Its 76° viewing angle and 590nm wavelength make it suitable for applications in automotive lighting, industrial signage, and general illumination where specific color output is critical. The component is supplied in trays.
Additional Information
Series: LZ1RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tray |
| Color | Amber |
| Wavelength | 590nm |
| Size / Dimension | 19.90mm Dia |
| Type | LED Module |
| Configuration | Starboard |
| Voltage - Forward (Vf) (Typ) | 2.6V |
| Height | 4.50mm |
| Current - Test | 1A |
| Viewing Angle | 76° |
| Lens Type | Domed |
| Current - Max | 1.2A |
| Lumens/Watt @ Current - Test | 32 lm/W |
| CCT (K) | - |
| CRI (Color Rendering Index) | - |
| Light Emitting Surface (LES) | 3.20mm Dia |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 84lm (75lm ~ 93lm) |
