GW KALRB3.EM-TUUQ-40H4
LED COB SOLERIQ WHT SQ 4000KManufacturer: ams-OSRAM USA INC.
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
ams-OSRAM USA INC. SOLERIQ® E30 series Chip On Board (COB) LED, part number GW-KALRB3-EM-TUUQ-40H4. This neutral white LED module offers a 4000K correlated color temperature with a CRI of 80. The square light-emitting surface (LES) has a diameter of 27.25mm, and the overall module dimensions are 36.00mm x 36.00mm. Designed for efficient illumination, it provides a typical luminous flux of 3665lm at 25°C, with a luminous efficacy of 122 lm/W at a test current of 700mA. The forward voltage is typically 44V, and it can handle a maximum current of 1.25A. The flat lens provides a wide 120° viewing angle. This component is suitable for general lighting applications, architectural lighting, and high-bay lighting systems. Packaged in trays.
Additional Information
Series: SOLERIQ® E30RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tray |
| Color | White, Neutral |
| Wavelength | - |
| Size / Dimension | 36.00mm L x 36.00mm W |
| Type | Chip On Board (COB) |
| Configuration | Square |
| Voltage - Forward (Vf) (Typ) | 44V |
| Height | 1.25mm |
| Current - Test | 700mA |
| Viewing Angle | 120° |
| Lens Type | Flat |
| Current - Max | 1.25A |
| Lumens/Watt @ Current - Test | 122 lm/W |
| CCT (K) | 4000K |
| CRI (Color Rendering Index) | 80 |
| Light Emitting Surface (LES) | 27.25mm Dia |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 3665lm (Typ) |
