AS1312-BWLT-45
IC REG BOOST 4.5V 400MA 8WLCSPManufacturer: ams-OSRAM USA INC.
Categories: DC DC Switching Regulators
Quality Control: Learn More
The ams-OSRAM USA INC. AS1312-BWLT-45 is a positive fixed output boost switching regulator IC. This component is designed for step-up voltage conversion, offering a fixed output of 4.5V with a maximum output current of 400mA. Operating within an input voltage range of 0.7V to 5V, it features a single positive output configuration and a non-synchronous boost topology. The AS1312-BWLT-45 is housed in an 8-WLCSP package, measuring 1.62x0.84, and is supplied on tape and reel. This device is suitable for applications in consumer electronics, portable devices, and industrial control systems. It operates across a temperature range of -40°C to 85°C.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-UFBGA, WLCSP |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Up |
| Current - Output | 400mA (Switch) |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Frequency - Switching | - |
| Voltage - Input (Max) | 5V |
| Topology | Boost |
| Supplier Device Package | 8-WLCSP (1.62x0.84) |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | - |
| Voltage - Input (Min) | 0.7V |
| Voltage - Output (Min/Fixed) | 4.5V |
