AS1751V-T
IC SW SPST-NOX4 900MOHM 16TQFNManufacturer: ams-OSRAM USA INC.
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
The ams-OSRAM USA INC. AS1751V-T is a quad single-pole, single-throw, normally open (SPST-NO) analog switch. This component features a low on-resistance of 900mOhm maximum, with channel-to-channel matching of 30mOhm. The device operates from a single supply voltage ranging from 1.6V to 3.6V. It offers fast switching times with a maximum turn-on time of 22ns and turn-off time of 14ns. Designed for surface mount applications, it is supplied in a 16-TQFN (3x3) package on tape and reel. The AS1751V-T is suitable for various applications, including consumer electronics and industrial control systems. Its typical channel capacitance is 45pF.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| On-State Resistance (Max) | 900mOhm |
| -3db Bandwidth | - |
| Supplier Device Package | 16-TQFN (3x3) |
| Voltage - Supply, Single (V+) | 1.6V ~ 3.6V |
| Voltage - Supply, Dual (V±) | - |
| Charge Injection | 2pC |
| Crosstalk | -80dB @ 1MHz |
| Switch Circuit | SPST - NO |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | 30mOhm |
| Switch Time (Ton, Toff) (Max) | 22ns, 14ns |
| Channel Capacitance (CS(off), CD(off)) | 45pF, 45pF |
| Current - Leakage (IS(off)) (Max) | 2.5nA |
| Number of Circuits | 4 |
