BLSC9G2731XS-200Z
RF MOSFET LDMOS 32V SOT1270-1Manufacturer: Ampleon USA Inc.
Categories: RF FETs, MOSFETs
Quality Control: Learn More
Ampleon USA Inc. BLSC9G2731XS-200Z is an RF LDMOS power transistor designed for high-frequency applications. This device operates within the 2.7 GHz to 3.1 GHz frequency range, delivering a 200W output power with a typical gain of 14dB at a 32V test voltage. The transistor features a 200mA test current and is housed in the SOT-1270-1 package for surface mounting. Its LDMOS technology enables robust performance in demanding environments. This component is suitable for use in base station infrastructure and other high-power RF systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | SOT-1270-1 |
| Current Rating (Amps) | 2.8µA |
| Mounting Type | Surface Mount |
| Frequency | 2.7GHz ~ 3.1GHz |
| Power - Output | 200W |
| Gain | 14dB |
| Technology | LDMOS |
| Noise Figure | - |
| Supplier Device Package | SOT-1270-1 |
| Voltage - Rated | 65 V |
| Voltage - Test | 32 V |
| Current - Test | 200 mA |
