BLC10G27XS-400AVTZ
RF MOSFET LDMOS 28V SOT1258-4Manufacturer: Ampleon USA Inc.
Categories: RF FETs, MOSFETs
Quality Control: Learn More
Ampleon USA Inc. BLC series RF LDMOS transistor, part number BLC10G27XS-400AVTZ, is a high-power device designed for demanding RF applications. This dual, common source MOSFET operates across a frequency range of 2.496GHz to 2.69GHz, delivering a nominal output power of 400W. Key performance specifications include a gain of 13.3dB and a test current of 750mA, with a rated voltage of 65V and a test voltage of 28V. Supplied in a SOT1258-4 package for surface mounting, this component finds application in base station infrastructure and other high-frequency power amplification systems.
Additional Information
Series: BLCRoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | SOT-1258-4 |
| Current Rating (Amps) | 2.8µA |
| Mounting Type | Surface Mount |
| Frequency | 2.496GHz ~ 2.69GHz |
| Configuration | Dual, Common Source |
| Power - Output | 400W |
| Gain | 13.3dB |
| Technology | LDMOS |
| Noise Figure | - |
| Supplier Device Package | SOT1258-4 |
| Voltage - Rated | 65 V |
| Voltage - Test | 28 V |
| Current - Test | 750 mA |
