BLA8G1011LS-300GU
RF MOSFET LDMOS 32V CDFM2Manufacturer: Ampleon USA Inc.
Categories: RF FETs, MOSFETs
Quality Control: Learn More
Ampleon USA Inc. presents the BLA8G1011LS-300GU, an RF LDMOS power transistor designed for demanding applications. This device operates at 1.06 GHz, delivering a robust 300W output power with a typical gain of 16.5dB at a test voltage of 32V. Engineered with LDMOS technology, it offers high efficiency and performance for RF power amplification. The component is housed in a CDFM2 package, suitable for chassis mounting, and is supplied in trays. Key specifications include a rated voltage of 65V and a test current of 150mA. This transistor is a critical component in base station infrastructure and other high-power RF systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: Not For New DesignsPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | SOT-502E |
| Current Rating (Amps) | - |
| Mounting Type | Chassis Mount |
| Frequency | 1.06GHz |
| Power - Output | 300W |
| Gain | 16.5dB |
| Technology | LDMOS |
| Noise Figure | - |
| Supplier Device Package | CDFM2 |
| Voltage - Rated | 65 V |
| Voltage - Test | 32 V |
| Current - Test | 150 mA |
