MA2CAP1200
12 POSITION STRAIGHT PLUG, CHECKManufacturer: Amphenol Sine Systems Corp
Categories: Circular Connector Housings
Quality Control: Learn More
12 Position Circular Connector Plug Housing Free Hanging (In-Line) Coupling Nut
Additional Information
Series: MotionGrade™ M23 Signal Standard Series, Checkmate™ Quick LockingRoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Features | Coupling Nut |
| Packaging | Box |
| Connector Type | Plug Housing |
| Mounting Type | Free Hanging (In-Line) |
| Shielding | Shielded |
| Number of Positions | 12 |
| Type | For Female Sockets or Male Pins |
| Orientation | P |
| Shell Size - Insert | M23-12 |
| Contact Type | Crimp |
| Fastening Type | Threaded |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Contact Size | 1.0mm |
| Material Flammability Rating | UL94 V-0 |
| Mounting Feature | - |
| Shell Size, MIL | - |
| Housing Color | Silver |
| Shell Material | Zinc Die Cast |
| Shell Finish | Nickel |
