RTS714ND12S0332
CONN RCPT FMALE 12P GOLD SOLDERManufacturer: Amphenol Sine Systems Corp
Categories: Circular Connector Assemblies
Quality Control: Learn More
12 Position Circular Connector Receptacle, Female Sockets Solder
Additional Information
Series: ecomate® Aquarius™RoHS Status: ROHS3 CompliantManufacturer Lead Time: 17 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Board Lock |
| Packaging | Bulk |
| Connector Type | Receptacle, Female Sockets |
| Color | Black |
| Voltage Rating | 500VAC/DC |
| Current Rating (Amps) | 13A |
| Mounting Type | Panel Mount, Through Hole |
| Shielding | Unshielded |
| Number of Positions | 12 |
| Orientation | N (Normal) |
| Shell Size - Insert | 14-12 |
| Operating Temperature | -40°C ~ 125°C |
| Fastening Type | Bayonet Lock |
| Termination | Solder |
| Ingress Protection | IP67/IP69K - Dust Tight, Water Resistant, Waterproof |
| Cable Opening | - |
| Material Flammability Rating | UL94 V-0 |
| Mounting Feature | Bulkhead - Front Side Nut |
| Shell Size, MIL | - |
| Contact Finish - Mating | Gold |
| Shell Material | Thermoplastic |
| Shell Finish | - |
| Primary Material | Plastic |
