FA1-NBRP-PCB-9
CONN FAKRA PLUG R/A 50 OHM PCBManufacturer: Amphenol RF
Categories: Coaxial Connector (RF) Assemblies
Quality Control: Learn More
Amphenol RF FA1-NBRP-PCB-9 is a right-angle Fakra plug connector designed for 50 Ohm impedance applications. This SMB-style connector features a male pin configuration with a locking ramp for secure mating. The center contact is constructed from brass, and the contact termination is achieved through solder. Its through-hole mounting type facilitates easy PCB integration. Rated for a maximum frequency of 6 GHz, this connector is suitable for demanding RF applications across automotive, telecommunications, and industrial sectors. The housing color is cream, and it supports solder shield termination.
Additional Information
Series: -RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | Code B |
| Packaging | Tray |
| Connector Type | Plug, Male Pin |
| Contact Termination | Solder |
| Impedance | 50 Ohms |
| Mounting Type | Through Hole, Right Angle |
| Cable Group | - |
| Fastening Type | Locking Ramp |
| Ingress Protection | - |
| Connector Style | SMB, Fakra |
| Mounting Feature | - |
| Housing Color | Cream |
| Shield Termination | Solder |
| Center Contact Material | Brass |
| Frequency - Max | 6 GHz |
| Number of Ports | 1 |
Request a Quote
