PS2P-LIN-CE-M002-3-AA-L0002-ELS120-05
2-PIECE TOUCHLESS HALL-EFFECT LIManufacturer: Amphenol Piher Sensing Systems
Categories: Angle, Linear Position Measuring
Quality Control: Learn More
Amphenol Piher Sensing Systems PS2P-LIN-CE-M002-3-AA-L0002-ELS120-05 is a touchless Hall effect sensor designed for linear position measurement. This component utilizes an external magnet actuator and features an included cable for termination. The PS2P-LIN series sensor provides an analog output signal that increases clockwise, with a calibrated linear range of 0 to 12mm. It offers a linearity of ±1% and operates within a temperature range of -40°C to 125°C. The device requires a supply voltage of 4.5V to 5.5V and is suitable for chassis mounting applications. This sensor is commonly employed in industrial automation, robotics, and automotive systems demanding precise linear position feedback.
Additional Information
Series: PS2P-LINRoHS Status: ROHS3 CompliantManufacturer Lead Time: 40 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Box with Wire Leads |
| Mounting Type | Chassis Mount |
| Output | Analog |
| Operating Temperature | -40°C ~ 125°C |
| Termination Style | Cable |
| Voltage - Supply | 4.5V ~ 5.5V |
| Linearity | ±1% |
| Linear Range | 0 ~ 12mm (0 ~ 0.47"") |
| Actuator Type | External Magnet, Included |
| Technology | Hall Effect |
| Resistance Tolerance | - |
| For Measuring | Linear Position |
| Supplier Device Package | - |
| Rotation Angle - Electrical, Mechanical | - |
| Output Signal | Clockwise Increase |
| Grade | - |
| Programmable | - |
| Qualification | - |
