MTS360-1A-C0000-ERA360-05K
SENSOR ANGLE 360DEG SMDManufacturer: Amphenol Piher Sensing Systems
Categories: Angle, Linear Position Measuring
Quality Control: Learn More
Amphenol Piher Sensing Systems MTS360 series Hall Effect sensor, part number MTS360-1A-C0000-ERA360-05K. This surface mount device measures 0° to 360° of angle, linearity ±1%, with an analog voltage output that increases clockwise. Designed for a supply voltage of 4.5V to 5V, it features a 16-SMD Module, 8 leads package. The MTS360-1A-C0000-ERA360-05K is suitable for applications requiring precise rotary position sensing across industrial, automotive, and consumer electronics sectors. Operating temperature range is -40°C to 125°C.
Additional Information
Series: MTS360RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 16-SMD Module, 8 Leads |
| Mounting Type | Surface Mount |
| Output | Analog Voltage |
| Operating Temperature | -40°C ~ 125°C |
| Termination Style | SMD (SMT) Tab |
| Voltage - Supply | 4.5V ~ 5V |
| Linearity | ±1% |
| Linear Range | - |
| Actuator Type | Hole for Shaft |
| Technology | Hall Effect |
| Resistance Tolerance | - |
| For Measuring | Angle, Linear, Rotary |
| Supplier Device Package | - |
| Rotation Angle - Electrical, Mechanical | 0° ~ 360° |
| Output Signal | Clockwise Increase |
| Programmable | - |
