10074703-001RLF
CONN RCP USB A/ESATA COMBO 7P RAManufacturer: Amphenol ICC (FCI)
Categories: USB, DVI, HDMI Connector Assemblies
Quality Control: Learn More
Amphenol ICC (FCI) offers the 10074703-001RLF, a USB-A and eSATA combo receptacle connector. This 7-position, through-hole, right-angle connector is designed for solder termination and features board guide and board lock functionalities for secure mounting. The horizontal orientation facilitates integration into compact system designs. This component is utilized in demanding applications within the consumer electronics, computing, and data storage industries. It is supplied in Tape & Reel packaging for automated assembly processes.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:&mpn=10074703-001RLF&lbl=1&lbc=000000&q3=1)
Technical Details:
| Features | Board Guide, Board Lock |
| Packaging | Tape & Reel (TR) |
| Voltage - Rated | - |
| Number of Contacts | 7 |
| Connector Type | USB-A (USB TYPE-A) and eSATA, Combo |
| Gender | Receptacle |
| Current Rating (Amps) | - |
| Mounting Type | Through Hole, Right Angle |
| Shielding | - |
| Operating Temperature | - |
| Specifications | - |
| Termination | Solder |
| Ingress Protection | - |
| Mounting Feature | Horizontal |
| Number of Ports | 1 |
