85968-101
CONN RCPT BLADE PWR 8POS PCBManufacturer: Amphenol ICC (FCI)
Categories: Specialized
Quality Control: Learn More
Amphenol ICC (FCI) Metral® series 85968-101 is an 8-position receptacle connector designed for power applications. This through-hole mount component features female blade sockets with a natural color and a gold contact finish, specified at 31.5µin (0.80µm). The connector supports an 8-position power contact layout and includes board guide and spacer features for enhanced PCB integration. Its robust construction and reliable mating interface make it suitable for demanding applications across industrial automation, telecommunications infrastructure, and datacenter equipment. The component is supplied in tube packaging.
Additional Information
Series: Metral®RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:&mpn=85968-101&lbl=1&lbc=000000&q3=1)
Technical Details:
| Features | Board Guide, Spacer |
| Packaging | Tube |
| Connector Type | Receptacle, Female Blade Sockets |
| Contact Finish | Gold |
| Color | Natural |
| Mounting Type | Through Hole |
| Number of Positions | 8 |
| Pitch | - |
| Number of Rows | 4 |
| Number of Positions Loaded | All |
| Termination | Solder |
| Connector Usage | - |
| Connector Style | Blade Power |
| Contact Finish Thickness | 31.5µin (0.80µm) |
| Contact Layout, Typical | 8 Power |
| Number of Columns | - |
