67230-004LF
CONN RCPT 4POS 0.1 GOLD PCB R/AManufacturer: Amphenol ICC (FCI)
Categories: Headers, Receptacles, Female Sockets
Quality Control: Learn More
Amphenol ICC (FCI) Dubox™ series receptacle connector, part number 67230-004LF. This 4-position, single-row connector features a 0.100" (2.54mm) pitch and is designed for right-angle, through-hole PCB mounting. The female socket contacts are finished with gold plating, 30.0µin (0.76µm) thick, for robust mating performance. The connector utilizes a push-pull fastening mechanism for secure engagement. Constructed with UL94 V-0 rated insulation in black, this component is suitable for applications in industrial automation and consumer electronics where reliable board-to-board connections are critical. Termination is via solder.
Additional Information
Series: Dubox™RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Connector Type | Receptacle |
| Voltage Rating | - |
| Current Rating (Amps) | - |
| Mounting Type | Through Hole, Right Angle |
| Number of Positions | 4 |
| Style | Board to Board |
| Operating Temperature | - |
| Contact Type | Female Socket |
| Fastening Type | Push-Pull |
| Number of Positions Loaded | All |
| Termination | Solder |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Mated Stacking Heights | - |
| Insulation Color | Black |
| Pitch - Mating | 0.100"" (2.54mm) |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Contact Finish - Post | - |
| Contact Length - Post | 0.115"" (2.92mm) |
| Insulation Height | 0.142"" (3.60mm) |
| Row Spacing - Mating | - |
| Number of Rows | 1 |
