79257-634
CONN HEADER R/A 34POS 2.54MMManufacturer: Amphenol ICC (FCI)
Categories: Headers, Male Pins
Quality Control: Learn More
Amphenol ICC (FCI) BERGSTIK® II series connector header, part number 79257-634. This right-angle, through-hole mounted header features 34 positions arranged in two rows with a 2.54mm (0.100") pitch. Constructed with phosphor bronze contacts and a Square male pin contact shape, it offers a mating contact finish of Gold or Gold, GXT™ with a thickness of 30.0µin (0.76µm). The header has a current rating of 3A and a contact length for mating of 0.230" (5.84mm). The insulation material is rated UL94 V-0, and the operating temperature range is -65°C to 130°C. This unshrouded header is suitable for board-to-board applications and is terminated via solder. It is commonly utilized in industrial automation and telecommunications equipment.
Additional Information
Series: BERGSTIK® IIRoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BagDatasheet:Download Free CAD Model:&mpn=79257-634&lbl=1&lbc=000000&q3=1)
Technical Details:
| Features | - |
| Packaging | Bag |
| Connector Type | Header |
| Voltage Rating | - |
| Current Rating (Amps) | 3A |
| Mounting Type | Through Hole, Right Angle |
| Number of Positions | 34 |
| Number of Rows | 2 |
| Style | Board to Board |
| Operating Temperature | -65°C ~ 130°C |
| Contact Type | Male Pin |
| Fastening Type | Push-Pull |
| Number of Positions Loaded | All |
| Termination | Solder |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Contact Material | Phosphor Bronze |
| Insulation Color | Black |
| Pitch - Mating | 0.100"" (2.54mm) |
| Contact Finish - Mating | Gold or Gold, GXT™ |
| Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Contact Finish - Post | - |
| Contact Shape | Square |
| Contact Length - Post | 0.120"" (3.05mm) |
| Insulation Height | 0.190"" (4.83mm) |
| Shrouding | Unshrouded |
| Overall Contact Length | - |
| Insulation Material | - |
| Row Spacing - Mating | 0.100"" (2.54mm) |
| Contact Length - Mating | 0.230"" (5.84mm) |
