78207-128
CONN HEADER R/A 28POS 2.54MMManufacturer: Amphenol ICC (FCI)
Categories: Headers, Male Pins
Quality Control: Learn More
Amphenol ICC (FCI) Mini-PV™, Basics+ Series header, part number 78207-128. This right-angle, through-hole mounted connector features 28 positions across two rows with a 0.100" (2.54mm) pitch. The male pin contacts are made of Phosphor Bronze with a mating contact finish of Gold or Gold, GXT™, 30.0µin (0.76µm) thick. Termination is via solder. Key features include a friction lock fastening system and a shrouding design with two walls. The insulation color is black and it meets UL94 V-0 material flammability rating. This component is suitable for board-to-cable/wire applications in industries such as telecommunications, industrial automation, and consumer electronics.
Additional Information
Series: Mini-PV™, Basics+RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:&mpn=78207-128&lbl=1&lbc=000000&q3=1)
Technical Details:
| Features | Keying Slot |
| Packaging | Bulk |
| Connector Type | Header |
| Voltage Rating | - |
| Current Rating (Amps) | - |
| Mounting Type | Through Hole, Right Angle |
| Number of Positions | 28 |
| Number of Rows | 2 |
| Style | Board to Cable/Wire |
| Operating Temperature | - |
| Contact Type | Male Pin |
| Fastening Type | Friction Lock |
| Number of Positions Loaded | All |
| Termination | Solder |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Contact Material | Phosphor Bronze |
| Insulation Color | Black |
| Pitch - Mating | 0.100"" (2.54mm) |
| Contact Finish - Mating | Gold or Gold, GXT™ |
| Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Contact Finish - Post | - |
| Contact Shape | Square |
| Contact Length - Post | 0.120"" (3.05mm) |
| Insulation Height | 0.303"" (7.70mm) |
| Shrouding | Shrouded - 2 Wall |
| Overall Contact Length | - |
| Insulation Material | - |
| Row Spacing - Mating | 0.100"" (2.54mm) |
| Contact Length - Mating | 0.230"" (5.84mm) |
