69192-110
CONN HEADER VERT 10POS 2.54MMManufacturer: Amphenol ICC (FCI)
Categories: Headers, Male Pins
Quality Control: Learn More
Amphenol ICC (FCI) BERGSTIK® II connector, part number 69192-110, is a 10-position, 2-row, unshrouded header designed for through-hole mounting. Featuring a 2.54mm (0.100") pitch, this male pin connector utilizes phosphor bronze contacts with a gold or GXT™ plating for the mating interface, offering a 30.0µin (0.76µm) thickness. The post contact length is 0.120" (3.05mm). This component supports a 3A current rating and operates within a temperature range of -65°C to 130°C. The insulation is black and rated UL94 V-0. Applications for this board-to-board connector include industrial automation, telecommunications, and consumer electronics.
Additional Information
Series: BERGSTIK® IIRoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:&mpn=69192-110&lbl=1&lbc=000000&q3=1)
Technical Details:
| Features | - |
| Packaging | Bulk |
| Connector Type | Header |
| Voltage Rating | - |
| Current Rating (Amps) | 3A |
| Mounting Type | Through Hole |
| Number of Positions | 10 |
| Number of Rows | 2 |
| Style | Board to Board |
| Operating Temperature | -65°C ~ 130°C |
| Contact Type | Male Pin |
| Fastening Type | Push-Pull |
| Number of Positions Loaded | All |
| Termination | Kinked Pin, Solder |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Contact Material | Phosphor Bronze |
| Insulation Color | Black |
| Pitch - Mating | 0.100"" (2.54mm) |
| Contact Finish - Mating | Gold or Gold, GXT™ |
| Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Contact Finish - Post | - |
| Contact Shape | Square |
| Contact Length - Post | 0.120"" (3.05mm) |
| Insulation Height | 0.100"" (2.54mm) |
| Shrouding | Unshrouded |
| Overall Contact Length | 0.450"" (11.43mm) |
| Insulation Material | - |
| Row Spacing - Mating | 0.100"" (2.54mm) |
| Contact Length - Mating | 0.230"" (5.84mm) |
