SFW20S-2STE1LF
CONN FFC FPC VERT 20POS 1MM SMDManufacturer: Amphenol ICC (FCI)
Categories: FFC, FPC (Flat Flexible) Connector Assemblies
Quality Control: Learn More
20 Position FFC, FPC Connector Contacts, Vertical - 1 Sided 0.039"" (1.00mm) Surface Mount
Additional Information
Series: SFWRoHS Status: ROHS3 CompliantManufacturer Lead Time: 9 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:&mpn=SFW20S-2STE1LF&lbl=1&lbc=000000&q3=1)
Technical Details:
| Features | Zero Insertion Force (ZIF) |
| Packaging | Tape & Reel (TR) |
| Contact Finish | Tin |
| Voltage Rating | 100V |
| Mounting Type | Surface Mount |
| Number of Positions | 20 |
| Pitch | 0.039"" (1.00mm) |
| Operating Temperature | -55°C ~ 105°C |
| Termination | Solder |
| Height Above Board | 0.209"" (5.30mm) |
| Locking Feature | - |
| Material Flammability Rating | UL94 V-0 |
| Actuator Material | Thermoplastic, Glass Filled |
| Contact Material | Phosphor Bronze |
| FFC, FCB Thickness | 0.33mm |
| Housing Material | Thermoplastic, Glass Filled |
| Cable End Type | - |
| Flat Flex Type | FFC, FPC |
| Connector/Contact Type | Contacts, Vertical - 1 Sided |
Request a Quote
