101-00313-68-02
CONN SD CARD PUSH-PUSH R/A SMDManufacturer: Amphenol ICC (Commercial Products)
Categories: PC Card Sockets
Quality Control: Learn More
Amphenol ICC (Commercial Products) offers the 101-00313-68-02, a 9-position Secure Digital (SD) card connector. This right-angle, surface-mount component features a push-in, push-out insertion and removal method, facilitating secure card engagement. Designed with a gold contact finish, including a 15.0µin (0.38µm) thickness, it ensures reliable connectivity for demanding applications. The connector incorporates a board guide feature for enhanced stability and positioning during assembly. Its compact profile, with a height above board of 0.106"" (2.70mm), makes it suitable for space-constrained designs. This connector is commonly utilized in consumer electronics, industrial automation, and embedded systems requiring robust memory card interfaces. The 101-00313-68-02 is supplied on Tape & Reel (TR) packaging.
Additional Information
Series: -RoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:&mpn=101-00313-68-02&lbl=1&lbc=000000&q3=1)
Technical Details:
| Features | Board Guide |
| Packaging | Tape & Reel (TR) |
| Connector Type | Connector and Ejector |
| Contact Finish | Gold |
| Mounting Type | Surface Mount, Right Angle |
| Number of Positions | 9 |
| Card Type | Secure Digital - SD |
| Height Above Board | 0.106"" (2.70mm) |
| Contact Finish Thickness | 15.0µin (0.38µm) |
| Mounting Feature | Normal, Standard - Top |
| Ejector Side | - |
| Insertion, Removal Method | Push In, Push Out |
