DLC-L10D-D4
SENSOR 0.36PSID 0.12"" 16BITManufacturer: Amphenol All Sensors Corporation
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Amphenol All Sensors Corporation DLC Series differential pressure sensor, part number DLC-L10D-D4. This surface mount component offers a ±0.36 PSI (±2.5 kPa) operating pressure range with a maximum of 7.25 PSI (50 kPa). It features a 0.12" (3mm) barbed tube port size and a dual top port configuration. The sensor provides a 16-bit I2C output and operates over a temperature range of -40°C to 85°C. Accuracy is rated at ±1.25%. It is suitable for board mount applications and is supplied in a 16-SOIC module package. Key applications include industrial automation and HVAC systems. The device operates from a 1.8V to 3.6V supply.
Additional Information
Series: DLCRoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Tube |
| Package / Case | 16-SOIC Module, Dual Top Ports |
| Output Type | I2C |
| Mounting Type | Surface Mount |
| Output | 16 b |
| Operating Pressure | ±0.36PSI (±2.5kPa) |
| Pressure Type | Differential |
| Accuracy | ±1.25% |
| Operating Temperature | -40°C ~ 85°C |
| Termination Style | Gull Wing |
| Voltage - Supply | 1.8V ~ 3.6V |
| Port Size | Male - 0.12"" (3mm) Tube, Dual |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | Barbed |
| Maximum Pressure | 7.25PSI (50kPa) |
