BSM-015G-LF
SENSOR 15PSIG .0795V 8LCCManufacturer: Amphenol All Sensors Corporation
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Amphenol All Sensors Corporation's BSM-015G-LF is a vented gauge pressure sensor designed for board-mount applications. This component offers an operating pressure range of 0 to 15 PSI (103.42kPa), with a maximum pressure rating of 45 PSI (310.26kPa). The analog voltage output spans from 0 mV to 79.5 mV, calibrated for a 3V supply. Featuring ±2% accuracy, it operates within a temperature range of -25°C to 85°C. The sensor is housed in an 8-CLCC (8-LCC) surface-mount package with SMD termination. This device is utilized in various industries including industrial and medical equipment where precise pressure monitoring is critical.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Package / Case | 8-CLCC |
| Output Type | Analog Voltage |
| Mounting Type | Surface Mount |
| Output | 0 mV ~ 79.5 mV (3V) |
| Operating Pressure | 15PSI (103.42kPa) |
| Pressure Type | Vented Gauge |
| Accuracy | ±2% |
| Operating Temperature | -25°C ~ 85°C |
| Termination Style | SMD (SMT) Tab |
| Voltage - Supply | 6V |
| Port Size | - |
| Applications | Board Mount |
| Supplier Device Package | 8-LCC |
| Port Style | No Port |
| Maximum Pressure | 45PSI (310.26kPa) |
