2 INCH-D1-4V-MINI
SENSOR 0.07PSID 4SIPManufacturer: Amphenol All Sensors Corporation
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Amphenol All Sensors Corporation MAMP series differential pressure sensor, part number 2-INCH-D1-4V-MINI. This module offers precise differential pressure measurement with an operating range of 0.07 PSI (0.5 kPa). Designed for board-level integration, it features through-hole mounting and PC pin termination. The sensor operates across a temperature range of -25°C to 85°C and includes temperature compensation for enhanced accuracy. Its 4-SIP module package is suitable for applications in industrial automation and medical equipment. The supply voltage range is 4.5V to 5.5V.
Additional Information
Series: MAMPRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Bulk |
| Package / Case | 4-SIP Module |
| Output Type | - |
| Mounting Type | Through Hole |
| Output | - |
| Operating Pressure | 0.07PSI (0.5kPa) |
| Pressure Type | Differential |
| Accuracy | - |
| Operating Temperature | -25°C ~ 85°C |
| Termination Style | PC Pin |
| Voltage - Supply | 4.5V ~ 5.5V |
| Port Size | - |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | - |
| Maximum Pressure | - |
