15 PSI-A-DO
SENSOR 15PSIA 0.19"" 12BITManufacturer: Amphenol All Sensors Corporation
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Amphenol All Sensors Corporation ADO series sensor, part number 15-PSI-A-DO. This absolute pressure sensor offers 15 PSI (103.42kPa) operating pressure with a maximum pressure rating of 60 PSI (413.69kPa). Designed for board mounting, it features a 0.19" (4.83mm) male tube port with a barbless style. The sensor provides a 12-bit SPI output and exhibits ±0.25% accuracy. It operates over a temperature range of -25°C to 90°C and requires a 7V supply voltage. Temperature compensation is integrated. The component is supplied in a 6-SIP module package with PC pin termination, suitable for through-hole mounting. This sensor is utilized in applications such as industrial automation and medical equipment.
Additional Information
Series: ADORoHS Status: Request inventory verificationManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Temperature Compensated |
| Packaging | Tube |
| Package / Case | 6-SIP Module |
| Output Type | SPI |
| Mounting Type | Through Hole |
| Output | 12 b |
| Operating Pressure | 15PSI (103.42kPa) |
| Pressure Type | Absolute |
| Accuracy | ±0.25% |
| Operating Temperature | -25°C ~ 90°C |
| Termination Style | PC Pin |
| Voltage - Supply | 7V |
| Port Size | Male - 0.19"" (4.83mm) Tube |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | Barbless |
| Maximum Pressure | 60PSI (413.69kPa) |
