HDB-M4-120M226X
MOTHER BOARD 120POSManufacturer: Amphenol Aerospace Operations
Categories: Specialized
Quality Control: Learn More
120 Connector Receptacle, Female Sockets Through Hole Black High Density (HDC, HDI, HPC)
Additional Information
Series: HBDRoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: 14 week(s)Product Status: ActivePackaging: BagDatasheet:Download Free CAD Model:
Technical Details:
| Features | Jackscrew |
| Packaging | Bag |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Tin-Lead |
| Color | Black |
| Mounting Type | Through Hole |
| Number of Positions | 120 |
| Pitch | 0.070"" (1.78mm) |
| Number of Rows | 12 |
| Number of Positions Loaded | All |
| Termination | Solder |
| Connector Usage | Backplane, Motherboard |
| Connector Style | High Density (HDC, HDI, HPC) |
| Contact Finish Thickness | 100.0µin (2.54µm) |
| Contact Layout, Typical | - |
| Number of Columns | 10 |
Request a Quote
