SP20C-G501 U
SENSOR 7.11PSIC 0.12"" .14VManufacturer: Amphenol Advanced Sensors
Categories: Pressure Sensors, Transducers
Quality Control: Learn More
Amphenol Advanced Sensors SP Series pressure sensor, part number SP20C-G501-U. This compound pressure sensor offers an operating range of ±7.11 PSI (±49.02 kPa) with a maximum pressure rating of -21.34 PSI (-147.13 kPa). Featuring a 0.12" (3mm) male tube port connection, this sensor utilizes a Wheatstone bridge output, providing a voltage range of 60 mV to 140 mV. The 6-DIP module package with through-hole mounting is suitable for board mount applications. Operating within a temperature range of -20°C to 100°C, this component is commonly found in industrial and medical equipment. Supplied on tape and reel for efficient assembly.
Additional Information
Series: SPRoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-DIP Module |
| Output Type | Wheatstone Bridge |
| Mounting Type | Through Hole |
| Output | 60 mV ~ 140 mV |
| Operating Pressure | ±7.11PSI (±49.02kPa) |
| Pressure Type | Compound |
| Accuracy | - |
| Operating Temperature | -20°C ~ 100°C |
| Termination Style | PC Pin |
| Voltage - Supply | - |
| Port Size | Male - 0.12"" (3mm) Tube |
| Applications | Board Mount |
| Supplier Device Package | - |
| Port Style | Barbless |
| Maximum Pressure | -21.34PSI (-147.13kPa) |
