XCVM1802-1LSIVSVA2197
IC VERSAL AICORE FPGA 2197BGAManufacturer: AMD
Categories: System On Chip (SoC)
Quality Control: Learn More
AMD Versal™ Prime Series XCVM1802-1LSIVSVA2197 is a System on Chip (SoC) featuring a powerful dual ARM® Cortex®-A72 MPCore™ and dual ARM® Cortex™-R5F processor configuration, enhanced with CoreSight™ technology. This Versal™ Prime FPGA integrates approximately 1.9 million logic cells, operating at clock speeds of 400MHz for the FPGA fabric and up to 1GHz for the processor cores. The device supports a wide range of connectivity options including CANbus, EBI/EMI, Ethernet, I2C, MMC/SD/SDIO, SPI, UART/USART, and USB OTG. On-chip peripherals include DDR memory controllers and DMA engines, along with PCIe support. The XCVM1802-1LSIVSVA2197 is housed in a 2197-FCBGA (45x45) package and operates within an industrial temperature range of -40°C to 100°C (TJ). This component is well-suited for demanding applications across automotive, aerospace and defense, and industrial automation sectors.
Additional Information
Series: Versal™ PrimeRoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 2197-BFBGA, FCBGA |
| Speed | 400MHz, 1GHz |
| RAM Size | 256KB |
| Operating Temperature | -40°C ~ 100°C (TJ) |
| Core Processor | Dual ARM® Cortex®-A72 MPCore™ with CoreSight™, Dual ARM®Cortex™-R5F with CoreSight™ |
| Primary Attributes | Versal™ Prime FPGA, 1.9M Logic Cells |
| Connectivity | CANbus, EBI/EMI, Ethernet, I2C, MMC/SD/SDIO, SPI, UART/USART, USB OTG |
| Peripherals | DDR, DMA, PCIe |
| Supplier Device Package | 2197-FCBGA (45x45) |
| Architecture | MPU, FPGA |
| Flash Size | - |
