XC9536-15PC44C
IC CPLD 36MC 15NS 44PLCCManufacturer: AMD
Categories: CPLDs (Complex Programmable Logic Devices)
Quality Control: Learn More
XC9536-15PC44C from AMD is a 5V, 36-macrocell CPLD from the XC9500 series. This device offers a propagation delay of 15 ns, supporting 34 I/O pins and featuring 800 gates. Designed for in-system programmability with a minimum of 10,000 program/erase cycles, it is packaged in a 44-PLCC (J-Lead) for surface mounting. The XC9536-15PC44C is suitable for applications in industrial automation, telecommunications, and consumer electronics where flexible logic implementation is required. Its internal voltage supply range is 4.75V to 5.25V.
Additional Information
Series: XC9500RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 44-LCC (J-Lead) |
| Mounting Type | Surface Mount |
| Programmable Type | In System Programmable (min 10K program/erase cycles) |
| Number of Gates | 800 |
| Number of Macrocells | 36 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Delay Time tpd(1) Max | 15 ns |
| Supplier Device Package | 44-PLCC (16.59x16.59) |
| Number of Logic Elements/Blocks | 2 |
| Voltage Supply - Internal | 4.75V ~ 5.25V |
| Number of I/O | 34 |
| Programmable | Not Verified |
