AOZ13937DI-02
32V IDEAL DIODE SINK SWITCH LATCManufacturer: Alpha & Omega Semiconductor Inc.
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
Power Switch/Driver 1:1 N-Channel 7A 12-DFN (3x3)
Additional Information
Series: ECPower™RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Load Discharge, Slew Rate Controlled, Status Flag |
| Packaging | Tape & Reel (TR) |
| Package / Case | 12-VFDFN Exposed Pad |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Interface | ON/OFF |
| Switch Type | USB Switch |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | High Side |
| Rds On (Typ) | 20mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | 3.4V ~ 32V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 7A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | 12-DFN (3x3) |
| Fault Protection | Current Limiting (Adjustable), Over Temperature, Over Voltage, Reverse Current, Short Circuit, UVLO |
