AOZ5007QI
IC REG BUCK 50A 40QFNManufacturer: Alpha & Omega Semiconductor Inc.
Categories: Full Half-Bridge (H Bridge) Drivers
Quality Control: Learn More
Alpha & Omega Semiconductor Inc.'s AOZ5007QI is a DrMOS synchronous buck converter featuring a half-bridge driver. This 40-QFN (6x6) package component delivers up to 30A continuous output current and 80A peak output current, with a load voltage range of 4.5V to 25V and a supply voltage of 4.5V to 5.5V. It incorporates essential fault protection mechanisms, including shoot-through and undervoltage lockout (UVLO). The device supports PWM interfacing and includes a bootstrap circuit and diode emulation for enhanced performance. Designed for surface mounting, the AOZ5007QI is suitable for inductive and capacitive loads. Typical applications for this component include advanced power management in computing, industrial, and high-performance consumer electronics. It operates within an ambient temperature range of -40°C to 85°C.
Additional Information
Series: DrMOSRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | Bootstrap Circuit, Diode Emulation |
| Packaging | Tape & Reel (TR) |
| Package / Case | 40-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Interface | PWM |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Half Bridge |
| Voltage - Supply | 4.5V ~ 5.5V |
| Rds On (Typ) | - |
| Applications | Synchronous Buck Converters |
| Current - Output / Channel | 30A |
| Current - Peak Output | 80A |
| Technology | DrMOS |
| Voltage - Load | 4.5V ~ 25V |
| Supplier Device Package | 40-QFN (6x6) |
| Fault Protection | Shoot Through, UVLO |
| Load Type | Inductive, Capacitive |
