AO4812

MOSFET 2N-CH 30V 6A 8SOIC

Manufacturer: Alpha & Omega Semiconductor Inc.

Categories: FET, MOSFET Arrays

Quality Control: Learn More

Alpha & Omega Semiconductor Inc. AO4812 is a dual N-channel Power MOSFET array designed for high-efficiency switching applications. This component features a Drain-Source Voltage (Vdss) of 30V and a continuous drain current (Id) of 6A at 25°C. The low on-resistance of 30mOhm is achieved at 6A and 10V Vgs, with a typical gate charge (Qg) of 6.3nC at 10V. Input capacitance (Ciss) is a maximum of 310pF at 15V. The device is housed in an 8-SOIC package with a surface mount configuration, offering a power dissipation of 2W. Operating temperature range is -55°C to 150°C. This MOSFET array is commonly utilized in power management solutions, automotive electronics, and consumer devices. The AO4812 is supplied in Tape & Reel (TR) packaging.

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Datasheet:
Technical Details:
PackagingTape & Reel (TR)
Package / Case8-SOIC (0.154"", 3.90mm Width)
Mounting TypeSurface Mount
Configuration2 N-Channel (Dual)
Operating Temperature-55°C ~ 150°C (TJ)
TechnologyMOSFET (Metal Oxide)
Power - Max2W
Drain to Source Voltage (Vdss)30V
Current - Continuous Drain (Id) @ 25°C6A
Input Capacitance (Ciss) (Max) @ Vds310pF @ 15V
Rds On (Max) @ Id, Vgs30mOhm @ 6A, 10V
Gate Charge (Qg) (Max) @ Vgs6.3nC @ 10V
FET Feature-
Vgs(th) (Max) @ Id2.4V @ 250µA
Supplier Device Package8-SOIC
