AOZ6238QI
IC SWITCH SPDT X 2 400MOHM 10QFNManufacturer: Alpha & Omega Semiconductor Inc.
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
Alpha & Omega Semiconductor Inc. AOZ6238QI is a dual 2:1 SPDT analog switch designed for efficient signal routing. This device features a low on-resistance of 400mOhm maximum with excellent channel-to-channel matching of 20mOhm. The 1.65V to 4.3V single supply voltage range and a -40°C to 85°C operating temperature make it suitable for applications requiring robust performance. With a -3dB bandwidth of 50MHz, low charge injection of 30pC, and crosstalk of -70dB at 100kHz, the AOZ6238QI is well-suited for use in consumer electronics and industrial control systems. The component is supplied in a compact 10-QFN (1.8x1.4) package on tape and reel.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 10-UFQFN |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| On-State Resistance (Max) | 400mOhm |
| -3db Bandwidth | 50MHz |
| Supplier Device Package | 10-QFN (1.8x1.4) |
| Voltage - Supply, Single (V+) | 1.65V ~ 4.3V |
| Voltage - Supply, Dual (V±) | - |
| Charge Injection | 30pC |
| Crosstalk | -70dB @ 100kHz |
| Switch Circuit | SPDT |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | 20mOhm |
| Switch Time (Ton, Toff) (Max) | 60ns, 35ns |
| Channel Capacitance (CS(off), CD(off)) | 15pF |
| Current - Leakage (IS(off)) (Max) | 50nA |
| Number of Circuits | 2 |
