AS4C32M16SA-7TCNTR
IC DRAM 512MBIT PAR 54TSOP IIManufacturer: Alliance Memory, Inc.
Categories: Memory
Quality Control: Learn More
Alliance Memory, Inc. AS4C32M16SA-7TCNTR is a 512Mbit Synchronous DRAM (SDRAM) memory component featuring a parallel interface. This device operates at a clock frequency of 143 MHz with an access time of 5.4 ns. The memory organization is 32M x 16, providing a substantial capacity for data storage. Designed for surface mounting, it is supplied in a 54-TSOP II package with a .400" width, delivered on tape and reel. The operating voltage range is 3V to 3.6V, and it is rated for an industrial temperature range of 0°C to 70°C. This SDRAM is suitable for applications requiring high-speed data buffering and storage, commonly found in consumer electronics, industrial control systems, and networking equipment. The write cycle time is specified at 2ns for word and page operations.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 54-TSOP (0.400"", 10.16mm Width) |
| Mounting Type | Surface Mount |
| Memory Size | 512Mbit |
| Memory Type | Volatile |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Voltage - Supply | 3V ~ 3.6V |
| Technology | SDRAM |
| Clock Frequency | 143 MHz |
| Memory Format | DRAM |
| Supplier Device Package | 54-TSOP II |
| Write Cycle Time - Word, Page | 2ns |
| Memory Interface | Parallel |
| Access Time | 5.4 ns |
| Memory Organization | 32M x 16 |
| Programmable | Not Verified |
