A1225LUA-T
MAGNETIC SWITCH LATCH 3SIPManufacturer: Allegro MicroSystems
Categories: Switches (Solid State)
Quality Control: Learn More
Allegro MicroSystems A1225LUA-T is a Hall Effect latching digital switch. This component features an open-drain output and is designed for operation with supply voltages ranging from 3.8V to 24V. It exhibits a high sensitivity with a trip field of 30mT and a release field of -30mT, responding specifically to south pole magnetic flux. The device is packaged in a 3-SIP (Supplier Device Package) format suitable for through-hole mounting. Maximum output current is 25mA with a supply current of 6mA. The A1225LUA-T is engineered for reliable performance across an operating temperature range of -40°C to 150°C (TA). This Hall effect sensor is utilized in applications such as position sensing, speed detection, and brushless DC motor commutation within the automotive and industrial sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 20 week(s)Product Status: Last Time BuyPackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | 3-SSIP |
| Output Type | Open Drain |
| Polarization | South Pole |
| Mounting Type | Through Hole |
| Function | Latch |
| Operating Temperature | -40°C ~ 150°C (TA) |
| Voltage - Supply | 3.8V ~ 24V |
| Technology | Hall Effect |
| Sensing Range | 30mT Trip, -30mT Release |
| Current - Output (Max) | 25mA |
| Current - Supply (Max) | 6mA |
| Supplier Device Package | 3-SIP |
| Test Condition | -40°C ~ 150°C |
