A6282ELP-T
IC LED DRVR LINEAR 50MA 24TSSOPManufacturer: Allegro MicroSystems
Categories: LED Drivers
Quality Control: Learn More
Allegro MicroSystems A6282ELP-T is a 16-output linear LED driver IC featuring a shift register topology for cascade control. This device is designed for applications requiring precise LED current regulation, with each channel capable of delivering up to 50mA. The A6282ELP-T integrates internal switches and supports a maximum output voltage of 12V, operating from supply voltages between 3V and 5.5V. Its 24-TSSOP-EP package with an exposed pad ensures efficient thermal management for surface mount applications. The driver offers a high operating frequency of 30MHz, suitable for demanding display backlighting and general illumination systems. Operating across an industrial temperature range of -40°C to 85°C, this component is ideal for automotive and consumer electronics sectors.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 24-TSSOP (0.173"", 4.40mm Width) Exposed Pad |
| Voltage - Output | 12V |
| Mounting Type | Surface Mount |
| Number of Outputs | 16 |
| Frequency | 30MHz |
| Type | Linear |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | Backlight |
| Current - Output / Channel | 50mA |
| Internal Switch(s) | Yes |
| Topology | Shift Register |
| Supplier Device Package | 24-TSSOP-EP |
| Dimming | - |
| Voltage - Supply (Min) | 3V |
| Voltage - Supply (Max) | 5.5V |
