D8751H
8-BIT, UVPROM, 8051 CPUManufacturer: Advanced Micro Devices
Categories: Microcontrollers
Quality Control: Learn More
The Advanced Micro Devices D8751H is an 8-bit microcontroller featuring an 8051 core processor operating at 12MHz. This component includes 4KB of EPROM for program memory and 128 bytes of RAM. It offers 32 general-purpose I/O pins and supports UART/USART connectivity. The D8751H is packaged in a 40-CDIP (0.600", 15.24mm) and is designed for through-hole mounting. Operating voltage is specified between 4.5V and 5.5V, with an operating temperature range of 0°C to 70°C. This device is commonly utilized in industrial automation and consumer electronics applications.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 40-CDIP (0.600"", 15.24mm) |
| Mounting Type | Through Hole |
| Speed | 12MHz |
| Program Memory Size | 4KB (4K x 8) |
| RAM Size | 128 x 8 |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Oscillator Type | External, Internal |
| Program Memory Type | EPROM |
| EEPROM Size | - |
| Core Processor | 8051 |
| Data Converters | - |
| Core Size | 8-Bit |
| Voltage - Supply (Vcc/Vdd) | 4.5V ~ 5.5V |
| Connectivity | UART/USART |
| Peripherals | - |
| Supplier Device Package | 40-CDIP |
| Number of I/O | 32 |
| Programmable | Not Verified |
Request a Quote
