XC4044EX-4PG411I
Field Programmable Gate Array, 1600 CLBs, 27000 Gates, 111MHz, CMOS, CPGA411Manufacturer: Advanced Micro Devices
Categories: Field Programmable Gate Arrays
Quality Control: Learn More
The Advanced Micro Devices XC4044EX-4PG411I is a Field Programmable Gate Array from the XC4044EX series, featuring 1600 Configurable Logic Blocks (CLBs) and an equivalent gate count of 27,000. This CMOS device operates at a maximum clock frequency of 111 MHz and supports a supply voltage range of 4.5V to 5.5V. The component is housed in a 411-terminal Ceramic Pin Grid Array (CPGA) package with a metal-sealed cofired construction. Its typical gate utilization extends from 27,000 to 80,000 gates. The operating temperature range is from -40°C to +100°C. This FPGA is suitable for applications in telecommunications, industrial control, and high-performance computing.
Additional Information
Series: XC4044EXRoHS Status: Manufacturer Lead Time: Product Status: ActivePackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Length | 52.3240 |
| Width | 52.3240 |
| Technology | CMOS |
| Additional_Feature | TYP. GATES = 27000-80000 |
| Clock_Frequency_Max | 111.00000 |
| Combinatorial_Delay_of_a_CLB_Max | 2.7000000000000000 |
| JESD_30_Code | S-CPGA-P411 |
| Number_of_CLBs | 1600 |
| Number_of_Equivalent_Gates | 27000 |
| Number_of_Inputs | 320 |
| Number_of_Outputs | 320 |
| Number_of_Terminals | 411 |
| Operating_Temperature_Max | 100.0 |
| Operating_Temperature_Min | -40.0 |
| Organization | 1600 CLBS, 27000 GATES |
| Package_Body_Material | CERAMIC, METAL-SEALED COFIRED |
| Package_Code | HIPGA |
| Package_Shape | Square |
| Package_Style | GRID ARRAY, HEAT SINK/SLUG, INTERSTITIAL PITCH |
| Programmable_Logic_Type | FIELD PROGRAMMABLE GATE ARRAY |
| Seated_Height_Max | 4.3180 |
| Supply_Voltage_Max | 5.50000 |
| Supply_Voltage_Min | 4.50000 |
| Supply_Voltage_Nom | 5 |
| Surface_Mount | No |
| Terminal_Form | PIN/PEG |
| Terminal_Pitch | 2.540 |
| Terminal_Position | Perpendicular |
