AM2864AE-250/BXA
EEPROM, 8KX8, 250ns, Parallel, NMOS, CDIP28Manufacturer: Advanced Micro Devices
Categories: EEPROMs
Quality Control: Learn More
The Advanced Micro Devices AM2864AE-250-BXA is a high-speed, parallel EEPROM with an 8KX8 memory organization, providing a total density of 65,536 bits. This NMOS technology device features a maximum access time of 250ns and a write cycle time of 10ms. Operating asynchronously, it supports data polling for efficient status monitoring. The component is housed in a 28-lead ceramic dual in-line package (CDIP28) with through-hole mounting. Designed for robust performance, it operates across an extended temperature range of -55°C to 125°C with a nominal supply voltage of 5V. Applications for this part include industrial control systems, telecommunications equipment, and military/aerospace electronics where reliable, non-volatile data storage is critical.
Additional Information
Series: AM2864RoHS Status: Manufacturer Lead Time: Product Status: DiscontinuedPackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Length | 35.5600 |
| Width | 15.2400 |
| Technology | NMOS |
| Access_Time_Max | 250.0000000000000000 |
| Command_User_Interface | No |
| Data_Polling | Yes |
| JESD_30_Code | R-CDIP-T28 |
| Memory_Density | 65536.0000000000000000 |
| Memory_IC_Type | EEPROM |
| Memory_Organization | 8KX8 |
| Memory_Width | 8 |
| Number_of_Functions | 1 |
| Number_of_Terminals | 28 |
| Number_of_Words | 8192.0000000000000000 |
| Number_of_Words_Code | 8k |
| Operating_Mode | Asynchronous |
| Operating_Temperature_Max | 125.0 |
| Operating_Temperature_Min | -55.0 |
| Output_Characteristics | 3-State |
| Package_Body_Material | CERAMIC, METAL-SEALED COFIRED |
| Package_Code | DIP |
| Package_Equivalence_Code | DIP28,.6 |
| Package_Shape | Rectangular |
| Package_Style | IN-LINE |
| Page_Size | 32 |
| Parallel_Serial | Parallel |
| Programming_Voltage | 5 |
| Screening_Level_Reference_Standard | 38535Q/M;38534H;883B |
| Seated_Height_Max | 4.4450 |
| Supply_Current_Max | 140.000000000000000 |
| Supply_Voltage_Max | 5.50000 |
| Supply_Voltage_Min | 4.50000 |
| Supply_Voltage_Nom | 5 |
| Surface_Mount | No |
| Terminal_Form | THROUGH-HOLE |
| Terminal_Pitch | 2.540 |
| Terminal_Position | Dual |
| Toggle_Bit | No |
| Write_Cycle_Time_Max_tWC | 10.0000000000000000 |
