ALD4213SCL
IC SW SPST-NO/NCX4 135OHM 16SOICManufacturer: Advanced Linear Devices Inc.
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
4 Circuit IC Switch 1:1 135Ohm 16-SOIC
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| On-State Resistance (Max) | 135Ohm |
| -3db Bandwidth | - |
| Supplier Device Package | 16-SOIC |
| Voltage - Supply, Single (V+) | 3V ~ 12V |
| Voltage - Supply, Dual (V±) | ±1.5V ~ 6V |
| Charge Injection | 0.2pC |
| Crosstalk | -90dB @ 100kHz |
| Switch Circuit | SPST - NO/NC |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | 2.7Ohm |
| Switch Time (Ton, Toff) (Max) | 130ns, 130ns |
| Channel Capacitance (CS(off), CD(off)) | 3pF, 3pF |
| Current - Leakage (IS(off)) (Max) | 100pA |
| Number of Circuits | 4 |
Request a Quote
