AMCA92-2R660G-S1F-T
RF ANT 2.7GHZ CHIP SOLDER SMDManufacturer: Abracon LLC
Categories: RF Antennas
Quality Control: Learn More
Abracon LLC AMCA series chip antenna, part number AMCA92-2R660G-S1F-T. This surface mount component is designed for high-performance RF applications operating in the 2.56GHz to 2.76GHz range, with a center frequency of 2.7GHz. Featuring a gain of 3dBi, this antenna is optimized for LTE, WiMax™, and WLAN standards, commonly found in cellular and WiFi communication systems. The compact design, with a maximum height of 1.00mm, suits space-constrained PCB layouts. It supports a maximum power handling of 3W and maintains a VSWR of 2. Packaged in a Tape & Reel (TR) format for automated assembly.
Additional Information
Series: AMCARoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Mounting Type | Surface Mount |
| Frequency Range | 2.56GHz ~ 2.76GHz |
| Applications | LTE, WiMax™, WLAN |
| Gain | 3dBi |
| Termination | Solder |
| Ingress Protection | - |
| Number of Bands | 1 |
| VSWR | 2 |
| Antenna Type | Chip |
| Height (Max) | 0.039"" (1.00mm) |
| Return Loss | - |
| Frequency Group | UHF (2GHz ~ 3GHz) |
| Frequency (Center/Band) | 2.7GHz |
| RF Family/Standard | Cellular, WiFi |
| Power - Max | 3 W |
