AMCA62-2R640G-01F-T
RF ANT 2.6GHZ CHIP SOLDER SMDManufacturer: Abracon LLC
Categories: RF Antennas
Quality Control: Learn More
The Abracon LLC AMCA62-2R640G-01F-T is a surface-mount chip antenna designed for 2.6GHz applications. This component, part of the AMCA series, operates within the UHF frequency group, specifically covering the 2.54GHz to 2.74GHz range with a center frequency of 2.6GHz. It offers a nominal gain of 2.6dBi and a VSWR of 2, supporting a maximum power handling of 3W. The antenna's compact form factor, with a maximum height of 1.00mm, makes it suitable for space-constrained designs. Termination is achieved via solder, and it is supplied on tape and reel for automated assembly. This component is utilized in BRS, WiMax™, and WLAN systems, and is compliant with standards such as 802.15.4, Bluetooth, and WiFi.
Additional Information
Series: AMCARoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Mounting Type | Surface Mount |
| Frequency Range | 2.54GHz ~ 2.74GHz |
| Applications | BRS, WiMax™, WLAN |
| Gain | 2.6dBi |
| Termination | Solder |
| Ingress Protection | - |
| Number of Bands | 1 |
| VSWR | 2 |
| Antenna Type | Chip |
| Height (Max) | 0.039"" (1.00mm) |
| Return Loss | - |
| Frequency Group | UHF (2GHz ~ 3GHz) |
| Frequency (Center/Band) | 2.6GHz |
| RF Family/Standard | 802.15.4, Bluetooth, WiFi |
| Power - Max | 3 W |
