AMCA52-2R540G-S1F-T
RF ANT 2.5GHZ CHIP SOLDER SMDManufacturer: Abracon LLC
Categories: RF Antennas
Quality Control: Learn More
Abracon LLC's AMCA52-2R540G-S1F-T is a single-band chip antenna designed for surface-mount applications. Operating within the 2.44GHz to 2.64GHz range with a center frequency of 2.5GHz, this component offers a typical gain of 2.5dBi. It is rated for a maximum power handling of 3W and features a VSWR of 2. The compact design, with a maximum height of 1.00mm, is suitable for space-constrained WiMax™ and WLAN systems. The antenna is supplied on tape and reel for efficient automated assembly. Its termination is solder, and it is classified within the UHF frequency group. This component is commonly utilized in wireless communication modules and embedded systems.
Additional Information
Series: AMCARoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Mounting Type | Surface Mount |
| Frequency Range | 2.44GHz ~ 2.64GHz |
| Applications | WiMax™, WLAN |
| Gain | 2.5dBi |
| Termination | Solder |
| Ingress Protection | - |
| Number of Bands | 1 |
| VSWR | 2 |
| Antenna Type | Chip |
| Height (Max) | 0.039"" (1.00mm) |
| Return Loss | - |
| Frequency Group | UHF (2GHz ~ 3GHz) |
| Frequency (Center/Band) | 2.5GHz |
| RF Family/Standard | WiFi |
| Power - Max | 3 W |
