AMCA52-2R350G-S1F-T
RF ANT 2.4GHZ CHIP SOLDER SMDManufacturer: Abracon LLC
Categories: RF Antennas
Quality Control: Learn More
The Abracon LLC AMCA52-2R350G-S1F-T is a miniature chip antenna designed for robust wireless communication. This component from the Abracon AMCA series operates at a center frequency of 2.4GHz, with a broad frequency range spanning 2.275GHz to 2.425GHz. It supports key wireless standards including LTE, WCS, WiMax™, and WLAN, making it suitable for demanding applications in the cellular and WiFi sectors.
Engineered for surface mount (SMD) integration, this antenna features a solder termination for reliable board-level connectivity. Fabricated with a high-quality chip antenna construction, it achieves a peak gain of 2.5dBi, and a VSWR of 2. The AMCA52-2R350G-S1F-T boasts a maximum power handling capability of 3W and a low profile with a maximum height of 0.043 inches (1.10mm). This component is supplied in Tape & Reel packaging for efficient automated assembly processes, ideal for high-volume production environments.
Additional Information
Series: AMCARoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Mounting Type | Surface Mount |
| Frequency Range | 2.275GHz ~ 2.425GHz |
| Applications | LTE, WCS, WiMax™, WLAN |
| Gain | 2.5dBi |
| Termination | Solder |
| Ingress Protection | - |
| Number of Bands | 1 |
| VSWR | 2 |
| Antenna Type | Chip |
| Height (Max) | 0.043"" (1.10mm) |
| Return Loss | - |
| Frequency Group | UHF (2GHz ~ 3GHz) |
| Frequency (Center/Band) | 2.4GHz |
| RF Family/Standard | Cellular, WiFi |
| Power - Max | 3 W |
