HWZT-2.00MD
CERAMIC RES 2.0000MHZ T/HManufacturer: Abracon LLC
Categories: Resonators
Quality Control: Learn More
Abracon LLC HWZT series ceramic resonator, part number HWZT-2-00MD, offers a precise 2 MHz fundamental frequency with a tight ±0.3% frequency stability and ±0.5% frequency tolerance. This through-hole mounted component features a nominal impedance of 100 Ohms and operates within a temperature range of -40°C to 85°C. The device is housed in a radial 2-lead package with a 5.00mm pitch, measuring 0.394" L x 0.197" W (10.00mm x 5.00mm) with a height of 0.217" (5.50mm). Its reliable performance makes it suitable for applications in consumer electronics and industrial control systems.
Additional Information
Series: HWZTRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial - 2 Lead, 5.00mm Pitch |
| Size / Dimension | 0.394"" L x 0.197"" W (10.00mm x 5.00mm) |
| Mounting Type | Through Hole |
| Type | Ceramic |
| Operating Temperature | -40°C ~ 85°C |
| Frequency Stability | ±0.3% |
| Height | 0.217"" (5.50mm) |
| Frequency Tolerance | ±0.5% |
| Impedance | 100 Ohms |
| Frequency | 2 MHz |
