HWZT-12.00RS
CERAMIC RES 12.0000MHZ T/HManufacturer: Abracon LLC
Categories: Resonators
Quality Control: Learn More
Abracon LLC HWZT-RS series ceramic resonator, part number HWZT-12-00RS, offers a precise 12 MHz fundamental frequency with a tight ±0.3% frequency stability and ±0.5% frequency tolerance. This through-hole component features a low impedance of 25 Ohms and operates within a temperature range of -25°C to 85°C. The radial package with formed leads, measuring 0.217"" L x 0.118"" W (5.50mm x 3.00mm) and a height of 0.217"" (5.50mm), is suitable for various industrial and consumer electronic applications. Its robust construction and reliable performance make it a key component in timing circuits for diverse systems.
Additional Information
Series: HWZT-RSRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial - 2 Lead, Formed |
| Size / Dimension | 0.217"" L x 0.118"" W (5.50mm x 3.00mm) |
| Mounting Type | Through Hole |
| Type | Ceramic |
| Operating Temperature | -25°C ~ 85°C |
| Frequency Stability | ±0.3% |
| Height | 0.217"" (5.50mm) |
| Frequency Tolerance | ±0.5% |
| Impedance | 25 Ohms |
| Frequency | 12 MHz |
Request a Quote
Clients Also Buy
HWZT-8.00RS
CERAMIC RES 8.0000MHZ T/H
HWZT-2.00MD
