ASTXR-12-38.400MHZ-514054-T
XTAL OSC TCXO 38.4000MHZ SNWVManufacturer: Abracon LLC
Categories: Oscillators
Quality Control: Learn More
Abracon LLC ASTXR-12 series TCXO, part number ASTXR-12-38-400MHZ-514054-T, provides a stable 38.4 MHz output. This surface mount component, housed in a 6-SMD, No Lead package, operates from a 3.3V supply and draws a maximum of 2mA. It features a clipped sine wave output and offers excellent frequency stability of ±500ppb over an operating temperature range of -40°C to 85°C. The compact dimensions of 2.50mm x 2.00mm, with a maximum seated height of 0.90mm, make it suitable for space-constrained applications. This oscillator is commonly utilized in telecommunications, industrial control systems, and consumer electronics. Supplied on tape and reel.
Additional Information
Series: ASTXR-12RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-SMD, No Lead |
| Size / Dimension | 0.098"" L x 0.079"" W (2.50mm x 2.00mm) |
| Mounting Type | Surface Mount |
| Output | Clipped Sine Wave |
| Function | - |
| Type | TCXO |
| Operating Temperature | -40°C ~ 85°C |
| Frequency Stability | ±500ppb |
| Voltage - Supply | 3.3V |
| Ratings | - |
| Current - Supply (Max) | 2mA |
| Height - Seated (Max) | 0.035"" (0.90mm) |
| Absolute Pull Range (APR) | - |
| Frequency | 38.4 MHz |
| Base Resonator | Crystal |
